Electric Plug-sliding Door

Applicable to passenger door systems of city buses

  • ≤120N (mean value)

    Anti-pinch force

  • Door open/close durability ≥ 2 million cycles

    Service life

  • (3-4) seconds

    Door open/close time

  • (Door opening width - 240) mm

    Free opening width

Technical Parameters

Product mode SPD-DE2-1400-W
(Electric double-leaf plug-sliding door outer seal)
SPD-DE2-1400-N
(Electric double-leaf plug-sliding door inner seal)
SPD-DE2-880
(Electric single-leaf plug-sliding door)
Free opening width (Door opening width -200) mm (Door opening width -240) mm (Door opening width -130) mm
Operating voltage DC24V
(DC18~32V)
(DC18~32V)
DC24V
(DC18~32V)
(DC18~32V)
DC24V
(DC18~32V)
(DC18~32V)
Working temperature -40℃~+80℃ -40℃~+80℃ -40℃~+80℃
Opening/closing time (3~4) seconds (3~4) seconds (3~4) seconds
Obstacle detection accuracy 30×60mm 30×60mm 30×60mm
Anti-pinch force Mean value ≤120N
Peak value ≤300N
Mean value ≤120N
Peak value ≤300N
Mean value ≤120N
Peak value ≤300N
Manual door open/close force (straight section) ≤100N ≤100N ≤100N
Service life Door open/close durability ≥ 2 million cycles Door open/close durability ≥ 2 million cycles Door open/close durability ≥ 2 million cycles


Unfold

Features

Safer

The door panel is equipped with sensitive edges and current-based anti-pinch configurations. Additionally, infrared anti-pinch and anti-drag systems can be optionally configured to maximize passenger safety.

More Reliable

The unique dual-rod and dual-slide-cylinder structure within the industry is adopted. Key components are sourced from world-class international suppliers (such as IGUS and Ewellix), meeting operational demands for 20 years (2 million door open/close cycles).

More Comfortable

The door panel is consistent with the overall vehicle design, enhancing the vehicle's coordination and aesthetics.

Smarter

The door has remote monitoring capabilities, enabling online monitoring and online fault diagnosis, and can display door abnormalities and other status.
